AbstractPrimaryMirror

class esis.optics.abc.AbstractPrimaryMirror

Bases: Printable, Rollable, Yawable, Pitchable, Translatable

An interface describing the primary mirror of the instrument.

Attributes

material	The optics material composing this object.
num_folds	The order of the rotational symmetry of the optical system.
pitch	pitch angle of this object
radius_clear	The clear radius of the aperture from center to vertex.
radius_mechanical	The radius of the mechanical aperture from center to vertex.
roll	roll angle of this object
sag	The sag function of this primary mirror.
surface	Represent this object as an optika surface.
transformation	the coordinate transformation between the global coordinate system and this object's local coordinate system
translation	translate the coordinate system
width_border	The width of the border around the clear aperture.
width_clear	The width of the clear aperture from edge to edge.
yaw	yaw angle of this object

Methods

__init__()
to_string([prefix])	Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

to_string(prefix=None)

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:

prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.

Return type:

str

abstract property material: None | AbstractMaterial

The optics material composing this object.

abstract property num_folds: Quantity | AbstractScalar

The order of the rotational symmetry of the optical system.

This is also the number of sides of the regular polygonal aperture.

abstract property pitch: Quantity | int | float | complex | ndarray | AbstractScalar

pitch angle of this object

property radius_clear: Quantity | AbstractScalar

The clear radius of the aperture from center to vertex.

Raises:

ValueError – If the number of sides is not an even number.

property radius_mechanical: Quantity | AbstractScalar

The radius of the mechanical aperture from center to vertex.

Raises:

ValueError – If the number of sides is not an even number.

abstract property roll: Quantity | int | float | complex | ndarray | AbstractScalar

roll angle of this object

abstract property sag: None | AbstractSag

The sag function of this primary mirror.

property surface: Surface

Represent this object as an optika surface.

property transformation: AbstractTransformation

the coordinate transformation between the global coordinate system and this object’s local coordinate system

abstract property translation: Quantity | AbstractScalar | AbstractVectorArray

translate the coordinate system

abstract property width_border: Quantity | AbstractScalar

The width of the border around the clear aperture.

abstract property width_clear: Quantity | AbstractScalar

The width of the clear aperture from edge to edge.

abstract property yaw: Quantity | int | float | complex | ndarray | AbstractScalar

yaw angle of this object
