AbstractInstrument#

class esis.optics.abc.AbstractInstrument[source]#

Bases: Printable, Rollable, Yawable, Pitchable

An interface describing the entire optical system.

Attributes

`angle_grating_input`	The angle between the grating normal and the direction of the incident light.
`angle_grating_output`	The angle between the grating normal and the direction of the diffracted light.
`axis_channel`	The name of the logical axis corresponding to changing camera channel.
`camera`	A model of the camera and sensors.
`central_obscuration`	A model of the central obscuration.
`field`	A default grid of field positions to trace through the system.
`field_stop`	A model of the field stop.
`filter`	A model of the thin-film filters.
`front_aperture`	A model of the front aperture plate.
`grating`	A model of the diffraction grating array.
`kwargs_plot`	Extra keyword arguments used to plot the optical system.
`name`	The human-readable name of the instrument.
`pitch`	pitch angle of this object
`primary_mirror`	A model of the primary mirror.
`pupil`	A default grid of pupil positions to trace through the system.
`roll`	roll angle of this object
`system`	Convert this model into an instance of `optika.systems.SequentialSystem`.
`transformation`	the coordinate transformation between the global coordinate system and this object's local coordinate system
`wavelength`	A default grid of wavelengths to trace through the system.
`wavelength_max`	The maximum wavelength permitted through the system.
`wavelength_min`	The minimum wavelength permitted through the system.
`wavelength_physical`	The value of `wavelength` converted to physical units if needed.
`yaw`	yaw angle of this object

Methods

`__init__`()
`to_string`([prefix])	Public-facing version of the `__repr__` method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

to_string(prefix=None)#

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:: prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.
Return type:: str

property angle_grating_input: AbstractScalar#

The angle between the grating normal and the direction of the incident light.

This is the incidence angle \(theta_i\) in the diffraction grating equation.

property angle_grating_output: AbstractScalar#

The angle between the grating normal and the direction of the diffracted light.

This is an analogue to the diffracted angle in the diffraction grating equation.

abstract property axis_channel#: The name of the logical axis corresponding to changing camera channel.

abstract property camera: None | Camera#: A model of the camera and sensors.

abstract property central_obscuration: None | AbstractCentralObscuration#: A model of the central obscuration.

abstract property field: None | AbstractCartesian2dVectorArray#: A default grid of field positions to trace through the system.

abstract property field_stop: None | AbstractFieldStop#: A model of the field stop.

abstract property filter: None | AbstractFilter#: A model of the thin-film filters.

abstract property front_aperture: None | AbstractFrontAperture#: A model of the front aperture plate.

abstract property grating: None | AbstractGrating#: A model of the diffraction grating array.

abstract property kwargs_plot#: Extra keyword arguments used to plot the optical system.

abstract property name: str#: The human-readable name of the instrument.

abstract property pitch: Quantity | int | float | complex | ndarray | AbstractScalar#: pitch angle of this object

abstract property primary_mirror: None | AbstractPrimaryMirror#: A model of the primary mirror.

abstract property pupil#: A default grid of pupil positions to trace through the system.

abstract property roll: Quantity | int | float | complex | ndarray | AbstractScalar#: roll angle of this object

property system: SequentialSystem#

Convert this model into an instance of optika.systems.SequentialSystem.

This is a cached property that is only computed once.

property transformation: AbstractTransformation#: the coordinate transformation between the global coordinate system and this object’s local coordinate system

abstract property wavelength: None | Quantity | AbstractScalar#

A default grid of wavelengths to trace through the system.

Can be either in normalized coordinates (in the range \(-1\) to \(+1\)) or in physical coordinates (with units of length).
