Sensor

class esis.optics.Sensor(manufacturer='Teledyne/e2v', family='CCD230-42', serial_number=None, grade=None, width_pixel=<Quantity 15. um>, num_pixel_x=2048, num_pixel_y=2064, num_blank=50, num_overscan=2, cte=<Quantity 99.9995 %>, readout_noise=<Quantity 4. electron>, readout_mode='transfer', temperature=<Quantity 248. K>, width_package_x=<Quantity 42. mm>, width_package_y=<Quantity 61. mm>, distance_radial=<Quantity 0. mm>, azimuth=<Quantity 0. deg>, translation=<Quantity 0. mm>, pitch=<Quantity 0. deg>, yaw=<Quantity 0. deg>, roll=<Quantity 0. deg>, position_image=<Quantity 0. mm>)

Bases: Printable, Rollable, Yawable, Pitchable, Translatable, CylindricallyTransformable, TeledyneCCD230

A model of the CCD sensors used to detect light.

Attributes

azimuth	The angle that the detector has been rotated about the axis of symmetry.
cte	The charge transfer efficiency of the sensor.
distance_radial	The distance between the axis of symmetry and the center of the detector.
family	The model number or product family of this sensor.
grade	The quality of the device.
manufacturer	The company which produced the sensor.
num_blank	The number of blank columns at the start of each row.
num_overscan	The number of overscan columns at the end of each row.
num_pixel	The number of pixels along the horizontal and vertical axes.
num_pixel_active	The number of pixels that are used to detect light.
num_pixel_x	The number of pixels along the horizontal axis of the CCD sensor.
num_pixel_y	The number of pixels along the vertical axis of the CCD sensor.
num_tap_x	The number of taps along the long axis of the CCD sensor.
num_tap_y	The number of taps along the short axis of the CCD sensor.
pitch	The pitch angle of this sensor.
position_image	The position of the center of the FOV on the sensor for the target wavelength.
readout_mode	The frame readout mode of the sensor.
readout_noise	The standard deviation of the error on each pixel value.
roll	The roll angle of this sensor.
serial_number	A unique number which identifies this sensor.
temperature	The operating temperature of this sensor.
transformation	the coordinate transformation between the global coordinate system and this object's local coordinate system
translation	An additional translation vector.
width_active	The physical size of the light sensitive area of the sensor.
width_package	The vertical and horizontal width of the physical sensor package.
width_package_x	The horizontal size of the physical sensor package.
width_package_y	The vertical size of the physical sensor package.
width_pixel	The physical size of a single pixel on the imaging sensor.
yaw	The yaw angle of this sensor.

Methods

__init__([manufacturer, family, ...])
dark_current([temperature])	Calculate the rate of charge accumulation when the sensor is not illuminated.
to_string([prefix])	Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

Parameters:

• manufacturer (str)

• family (str)

• serial_number (None | str)

• grade (None | str)

• width_pixel (Quantity)

• num_pixel_x (int)

• num_pixel_y (int)

• num_blank (int)

• num_overscan (int)

• cte (Quantity)

• readout_noise (Quantity)

• readout_mode (Literal['full-frame', 'transfer'])

• temperature (Quantity | AbstractScalar)

• width_package_x (Quantity)

• width_package_y (Quantity)

• distance_radial (Quantity | AbstractScalar)

• azimuth (Quantity | AbstractScalar)

• translation (Quantity | AbstractCartesian3dVectorArray)

• pitch (Quantity | AbstractScalar)

• yaw (Quantity | AbstractScalar)

• roll (Quantity | AbstractScalar)

• position_image (Quantity | AbstractCartesian2dVectorArray)

dark_current(temperature=None)

Calculate the rate of charge accumulation when the sensor is not illuminated.

Parameters:

temperature (None | Quantity | AbstractScalar) – The temperature of the sensor. If None, the value of temperature is used.

Examples

to_string(prefix=None)

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:

prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.

Return type:

str

azimuth: Quantity | AbstractScalar = <Quantity 0. deg>

The angle that the detector has been rotated about the axis of symmetry.

cte: u.Quantity = <Quantity 99.9995 %>

The charge transfer efficiency of the sensor.

distance_radial: Quantity | AbstractScalar = <Quantity 0. mm>

The distance between the axis of symmetry and the center of the detector.

family: str = 'CCD230-42'

The model number or product family of this sensor.

grade: None | str = None

The quality of the device.

Grade 0 is the best possible and Grade 5 is the worst possible.

manufacturer: str = 'Teledyne/e2v'

The company which produced the sensor.

num_blank: int = 50

The number of blank columns at the start of each row.

num_overscan: int = 2

The number of overscan columns at the end of each row.

property num_pixel: Cartesian2dVectorArray

The number of pixels along the horizontal and vertical axes.

property num_pixel_active

The number of pixels that are used to detect light.

If readout_mode is "full-frame", then this is the same as num_pixel. If readout_mode is "transfer", then the vertical component of num_pixel is divided by 2 since half of the sensor is now used for charge storage.

num_pixel_x: int = 2048

The number of pixels along the horizontal axis of the CCD sensor.

num_pixel_y: int = 2064

The number of pixels along the vertical axis of the CCD sensor.

num_tap_x: ClassVar[int] = 2

The number of taps along the long axis of the CCD sensor.

num_tap_y: ClassVar[int] = 2

The number of taps along the short axis of the CCD sensor.

pitch: Quantity | AbstractScalar = <Quantity 0. deg>

The pitch angle of this sensor.

position_image: Quantity | AbstractCartesian2dVectorArray = <Quantity 0. mm>

The position of the center of the FOV on the sensor for the target wavelength.

readout_mode: Literal['full-frame', 'transfer'] = 'transfer'

The frame readout mode of the sensor.

Either the entire sensor is read at the same time ("full-frame"), or half of the sensor is used for storage ("transfer").

readout_noise: u.Quantity = <Quantity 4. electron>

The standard deviation of the error on each pixel value.

roll: Quantity | AbstractScalar = <Quantity 0. deg>

The roll angle of this sensor.

serial_number: None | str = None

A unique number which identifies this sensor.

temperature: u.Quantity | na.AbstractScalar = <Quantity 248. K>

The operating temperature of this sensor.

property transformation: AbstractTransformation

the coordinate transformation between the global coordinate system and this object’s local coordinate system

translation: Quantity | AbstractCartesian3dVectorArray = <Quantity 0. mm>

An additional translation vector.

property width_active

The physical size of the light sensitive area of the sensor.

property width_package: Cartesian2dVectorArray

The vertical and horizontal width of the physical sensor package.

width_package_x: u.Quantity = <Quantity 42. mm>

The horizontal size of the physical sensor package.

width_package_y: u.Quantity = <Quantity 61. mm>

The vertical size of the physical sensor package.

width_pixel: u.Quantity = <Quantity 15. um>

The physical size of a single pixel on the imaging sensor.

yaw: Quantity | AbstractScalar = <Quantity 0. deg>

The yaw angle of this sensor.
