Grating

class esis.optics.Grating(serial_number='', manufacturing_number='', angle_input=<Quantity 0. deg>, angle_output=<Quantity 0. deg>, sag=None, material=None, rulings=None, num_folds=0, halfwidth_inner=<Quantity 0. mm>, halfwidth_outer=<Quantity 0. mm>, width_border=<Quantity 0. mm>, width_border_inner=<Quantity 0. mm>, clearance=<Quantity 0. mm>, distance_radial=<Quantity 0. mm>, azimuth=<Quantity 0. deg>, translation=<Quantity 0. mm>, pitch=<Quantity 0. deg>, yaw=<Quantity 0. deg>, roll=<Quantity 0. deg>)

Bases: AbstractGrating

A model of the diffraction gratings of this instrument.

Attributes

angle_aperture	The angle of the grating's aperture.
angle_input	The nominal angle of the incident light from the field stop.
angle_output	The nominal angle of reflected light to the detectors.
azimuth	The angle of rotation about the axis of symmetry.
clearance	The minimum distance between adjacent physical gratings.
distance_radial	The distance of this object from the axis of symmetry.
halfwidth_inner	The distance from the apex to the inner edge of the clear aperture.
halfwidth_outer	The distance from the apex to the outer edge of the clear aperture.
manufacturing_number	An additional number describing this diffraction grating.
material	The optical material composing this grating.
num_folds	The order of the rotational symmetry of the optical system.
pitch	The pitch angle of this object.
roll	The roll angle of this object
rulings	The ruling pattern of this grating.
sag	The sag function of this grating.
serial_number	The serial number of this diffraction grating.
surface	Represent this object as an optika surface.
transformation	the coordinate transformation between the global coordinate system and this object's local coordinate system
translation	A transformation which can arbitrarily translate this object.
width_border	The nominal width of the border around the clear aperture.
width_border_inner	The width of the border on the narrow edge of the grating.
yaw	The yaw angle of this object.

Methods

__init__([serial_number, ...])
to_string([prefix])	Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

Parameters:

• serial_number (str)

• manufacturing_number (str)

• angle_input (Quantity)

• angle_output (Quantity)

• sag (None | AbstractSag)

• material (None | AbstractMaterial)

• rulings (None | AbstractRulings)

• num_folds (int)

• halfwidth_inner (Quantity | AbstractScalar)

• halfwidth_outer (Quantity | AbstractScalar)

• width_border (Quantity | AbstractScalar)

• width_border_inner (Quantity | AbstractScalar)

• clearance (Quantity | AbstractScalar)

• distance_radial (Quantity | AbstractScalar)

• azimuth (Quantity | AbstractScalar)

• translation (Quantity | AbstractCartesian3dVectorArray)

• pitch (Quantity | AbstractScalar)

• yaw (Quantity | AbstractScalar)

• roll (Quantity | AbstractScalar)

to_string(prefix=None)

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:

prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.

Return type:

str

property angle_aperture: Quantity | AbstractScalar

The angle of the grating’s aperture.

This is equal to \(2 \pi / n\) radians, where \(n\) is the order of the rotational symmetry of the optical system.

angle_input: Quantity = <Quantity 0. deg>

The nominal angle of the incident light from the field stop.

angle_output: Quantity = <Quantity 0. deg>

The nominal angle of reflected light to the detectors.

azimuth: Quantity | AbstractScalar = <Quantity 0. deg>

The angle of rotation about the axis of symmetry.

clearance: Quantity | AbstractScalar = <Quantity 0. mm>

The minimum distance between adjacent physical gratings.

distance_radial: Quantity | AbstractScalar = <Quantity 0. mm>

The distance of this object from the axis of symmetry.

halfwidth_inner: Quantity | AbstractScalar = <Quantity 0. mm>

The distance from the apex to the inner edge of the clear aperture.

halfwidth_outer: Quantity | AbstractScalar = <Quantity 0. mm>

The distance from the apex to the outer edge of the clear aperture.

manufacturing_number: str = ''

An additional number describing this diffraction grating.

material: None | AbstractMaterial = None

The optical material composing this grating.

num_folds: int = 0

The order of the rotational symmetry of the optical system.

This determines the aperture wedge angle of this grating.

pitch: Quantity | AbstractScalar = <Quantity 0. deg>

The pitch angle of this object.

roll: Quantity | AbstractScalar = <Quantity 0. deg>

The roll angle of this object

rulings: None | AbstractRulings = None

The ruling pattern of this grating.

sag: None | AbstractSag = None

The sag function of this grating.

serial_number: str = ''

The serial number of this diffraction grating.

property surface: Surface

Represent this object as an optika surface.

property transformation: AbstractTransformation

the coordinate transformation between the global coordinate system and this object’s local coordinate system

translation: Quantity | AbstractCartesian3dVectorArray = <Quantity 0. mm>

A transformation which can arbitrarily translate this object.

width_border: Quantity | AbstractScalar = <Quantity 0. mm>

The nominal width of the border around the clear aperture.

width_border_inner: Quantity | AbstractScalar = <Quantity 0. mm>

The width of the border on the narrow edge of the grating.

yaw: Quantity | AbstractScalar = <Quantity 0. deg>

The yaw angle of this object.
