Filter

class esis.optics.Filter(material=None, radius_clear=<Quantity 0. mm>, width_border=<Quantity 0. mm>, distance_radial=<Quantity 0. mm>, azimuth=<Quantity 0. deg>, translation=<Quantity 0. mm>, pitch=<Quantity 0. deg>, yaw=<Quantity 0. deg>, roll=<Quantity 0. deg>)

Bases: AbstractFilter

A model of the visible-light filters of the instrument.

These are thin-film filters supported by a fine mesh.

Attributes

azimuth	The angle of rotation about the axis of symmetry.
distance_radial	The distance of this object from the axis of symmetry.
material	A model of the filter material including the mesh and oxide.
pitch	The pitch angle of this object.
radius_clear	The radius of the filter's circular clear aperture.
roll	The roll angle of this object
surface	Represent this object as an optika surface.
transformation	the coordinate transformation between the global coordinate system and this object's local coordinate system
translation	A transformation which can arbitrarily translate this object.
width_border	The width of the frame around the clear aperture.
yaw	The yaw angle of this object.

Methods

__init__([material, radius_clear, ...])
to_string([prefix])	Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

Parameters:

• material (None | AbstractMaterial)

• radius_clear (Quantity | AbstractScalar)

• width_border (Quantity | AbstractScalar)

• distance_radial (Quantity | AbstractScalar)

• azimuth (Quantity | AbstractScalar)

• translation (Quantity | AbstractCartesian3dVectorArray)

• pitch (Quantity | AbstractScalar)

• yaw (Quantity | AbstractScalar)

• roll (Quantity | AbstractScalar)

to_string(prefix=None)

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:

prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.

Return type:

str

azimuth: Quantity | AbstractScalar = <Quantity 0. deg>

The angle of rotation about the axis of symmetry.

distance_radial: Quantity | AbstractScalar = <Quantity 0. mm>

The distance of this object from the axis of symmetry.

material: None | AbstractMaterial = None

A model of the filter material including the mesh and oxide.

pitch: Quantity | AbstractScalar = <Quantity 0. deg>

The pitch angle of this object.

radius_clear: Quantity | AbstractScalar = <Quantity 0. mm>

The radius of the filter’s circular clear aperture.

roll: Quantity | AbstractScalar = <Quantity 0. deg>

The roll angle of this object

property surface: Surface

Represent this object as an optika surface.

property transformation: AbstractTransformation

the coordinate transformation between the global coordinate system and this object’s local coordinate system

translation: Quantity | AbstractCartesian3dVectorArray = <Quantity 0. mm>

A transformation which can arbitrarily translate this object.

width_border: Quantity | AbstractScalar = <Quantity 0. mm>

The width of the frame around the clear aperture.

yaw: Quantity | AbstractScalar = <Quantity 0. deg>

The yaw angle of this object.
