AbstractFilter

class esis.optics.abc.AbstractFilter

Bases: Printable, Rollable, Yawable, Pitchable, Translatable, CylindricallyTransformable

An interface describing the visible-light filters of the instrument.

Attributes

azimuth	The angle of rotation about the axis of symmetry.
distance_radial	The distance of this object from the axis of symmetry.
material	A model of the filter material including the mesh and oxide.
pitch	pitch angle of this object
radius_clear	The radius of the filter's circular clear aperture.
roll	roll angle of this object
surface	Represent this object as an optika surface.
transformation	the coordinate transformation between the global coordinate system and this object's local coordinate system
translation	translate the coordinate system
width_border	The width of the frame around the clear aperture.
yaw	yaw angle of this object

Methods

__init__()
to_string([prefix])	Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Inheritance Diagram

to_string(prefix=None)

Public-facing version of the __repr__ method that allows for defining a prefix string, which can be used to calculate how much whitespace to add to the beginning of each line of the result.

Parameters:

prefix (None | str) – an optional string, the length of which is used to calculate how much whitespace to add to the result.

Return type:

str

abstract property azimuth: Quantity | AbstractScalar

The angle of rotation about the axis of symmetry.

abstract property distance_radial: Quantity | AbstractScalar

The distance of this object from the axis of symmetry.

abstract property material: AbstractThinFilmFilter

A model of the filter material including the mesh and oxide.

abstract property pitch: Quantity | int | float | complex | ndarray | AbstractScalar

pitch angle of this object

abstract property radius_clear: Quantity | AbstractScalar

The radius of the filter’s circular clear aperture.

abstract property roll: Quantity | int | float | complex | ndarray | AbstractScalar

roll angle of this object

property surface: Surface

Represent this object as an optika surface.

property transformation: AbstractTransformation

the coordinate transformation between the global coordinate system and this object’s local coordinate system

abstract property translation: Quantity | AbstractScalar | AbstractVectorArray

translate the coordinate system

abstract property width_border: Quantity | AbstractScalar

The width of the frame around the clear aperture.

abstract property yaw: Quantity | int | float | complex | ndarray | AbstractScalar

yaw angle of this object
